Lenovo LEGION 5 16IRX9 GAMING 14th Gen Intel Core™ i9-14900HX (83DG00AGUS)
Place your order before 12:00pm and receive it by tomorrow
Product Description
Model Configurations
| PERFORMANCE | |
| Processor |
Intel® Core™ i9-14900HX, 24C (8P + 16E) / 32T, P-core 2.2 / 5.8GHz, E-core 1.6 / 4.1GHz, 36MB |
| AI PC Category |
AI-Powered Gaming PC |
| Graphics |
NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W, 233 AI TOPS |
| Chipset |
Intel® HM770 Chipset |
| Memory |
2x 16GB SO-DIMM DDR5-5600 |
| Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable |
| Max Memory |
Up to 64GB DDR5-5600 |
| Storage |
1TB SSD M.2 2280 PCIe® 4.0x4 NVMe® |
| Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB |
| Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots |
| Card Reader |
microSD Card Reader |
| Optical |
None |
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec |
| Speakers |
Stereo speakers, 2W x2, optimized with Nahimic Audio |
| Camera |
FHD 1080p with E-shutter |
| Microphone |
2x, Array |
| Battery |
80Wh |
| Power Adapter |
230W Slim Tip (3-pin) |
| Special Features |
AI Chip: LA1 |
| DESIGN | |
| Display |
16" WQXGA (2560x1600) IPS 500nits Anti-glare, 100% sRGB, 240Hz, DisplayHDR™ 400, Dolby Vision®, G-SYNC®, Low Blue Light |
| Touchscreen |
None |
| Color Calibration |
Factory Color Calibration |
| Keyboard |
4-Zone RGB Backlit, English (US) |
| Touchpad |
Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches) |
| Case Color |
Luna Grey |
| Surface Treatment |
Aluminium Stamping (Anodized with Sandblasting) |
| Case Material |
Aluminium (Top), PC-ABS (Bottom) |
| Pen |
Pen Not Supported |
| Dimensions (WxDxH) |
359.7 x 262.3 x 19.7-25.2 mm (14.16 x 10.33 x 0.78-0.99 inches) |
| Weight |
Around 2.36 kg (5.2 lbs) |
| SOFTWARE | |
| Operating System |
Windows® 11 Home, English |
| Bundled Software |
Office Trial |
| CONNECTIVITY | |
| WLAN + Bluetooth |
Wi-Fi® 6E, 802.11ax 2x2 + BT5.2 |
| WWAN |
Non-WWAN |
| Ethernet |
100/1000M (RJ-45) |
| Standard Ports |
|
| SECURITY & PRIVACY | |
| Security Chip |
Firmware TPM 2.0 Enabled |
| Fingerprint Reader |
None |
| Other Security |
E-shutter |
| SERVICE | |
| Base Warranty |
1-year, Courier or Carry-in |
| Included Upgrade |
None |
| ACCESSORIES | |
| Bundled Accessories |
None |
| CERTIFICATIONS | |
| Green Certifications |
|
| Other Certifications |
TÜV Rheinland® Low Blue Light (Hardware Solution) |
| MODEL INFORMATION | |
| Model |
83DG00AGUS |
| Country/Region |
USA |
| Announce Date |
2024-02-02 |
| End of Support |
2030-01-25 |
